6 BEROOMS DOUBLE STOREY

GROUND FLOOR

GARAGE

4 BED

STUDY

LAUNDRY

TOP FLOOR

2 BED

LOUNGE

2 BATH

Design Description

GROUND FLOOR:

•Study

  • Floor Area: 18.231 m²
  • Description: at the back left of the house, off the left side of the passage and above the laundry; contains windows.

•Patio

  • Floor Area: 8.962 m²
  • Description: at the back left, above the study/bedroom wing and beside the stair area; contains no internal fixtures shown.

•Laundry

  • Floor Area: 8.915 m²
  • Description: on the left side of the house, below the study and off the passage; contains no fixtures shown.

•Bedroom

  • Floor Area: 11.381 m²
  • Description: left of the bathroom and above the passage, between the study and bathroom; contains a bed and built-in cupboards.

•Bathroom

  • Floor Area: 7.685 m²
  • Description: above the passage between two bedrooms; contains bath, shower, toilet and double basin.

•Bedroom

  • Floor Area: 16.783 m²
  • Description: to the right of the bathroom and above the lounge; contains a bed and built-in cupboards.

•Kitchen

  • Floor Area: 28.084 m²
  • Description: at the back right, above the lounge and left of the entrance hall; contains counters, sink, stove and an island/breakfast counter.

•Patio

  • Floor Area: 9.941 m²
  • Description: outside the kitchen at the back; contains no internal fixtures shown.

•Passage

  • Floor Area: 26.855 m²
  • Description: central circulation space linking the left and middle bedrooms, bathroom, main bedroom suite, lounge and laundry/study wing; contains no fixtures shown.

•Main Bedroom

  • Floor Area: 28.639 m²
  • Description: front left of the house, off the passage and left of the WIC/ensuite; contains a bed and built-in cupboards.

•WIC

  • Floor Area: 10.268 m²
  • Description: between the main bedroom and ensuite; contains wardrobe/storage layout.

•En Suite

  • Floor Area: 8.445 m²
  • Description: next to the WIC, between the main bedroom and front middle bedroom; contains bath, shower, toilet and basin.

•Bedroom

  • Floor Area: 19.360 m²
  • Description: front middle, right of the ensuite and below the upper middle bedroom; contains a bed and built-in cupboards.

•Lounge

  • Floor Area: 59.856 m²
  • Description: central-right, below the kitchen and left of the entrance hall, with a curved front wall; contains sofas, chairs, coffee table, dining table and stairs.

•Ent Hall

  • Floor Area: 9.615 m²
  • Description: right of the lounge, between the lounge and double garage; contains no fixtures shown.

•Patio

  • Floor Area: 8.580 m²
  • Description: below the entrance hall and right of the lounge; contains no internal fixtures shown.

•Patio

  • Floor Area: 13.122 m²
  • Description: below the front middle bedroom and in front of the lounge curve; contains no internal fixtures shown.

•Patio

  • Floor Area: 12.534 m²
  • Description: in front of the main bedroom at the front left; contains no internal fixtures shown.

•Double Garage

  • Floor Area: 67.143 m²
  • Description: detached/right side of the plan, connected near the entrance hall side; contains space for two vehicles.

FIRST FLOOR:

•En Suite

  • Floor Area: 5.989 m²
  • Description: at the back left of the upper floor, next to the WIC and main bedroom; contains bath, shower and toilet.

•WIC

  • Floor Area: 6.313 m²
  • Description: below the ensuite and left of the upper main bedroom; contains wardrobe/storage layout.

•Main Bedroom

  • Floor Area: 24.128 m²
  • Description: upper middle-left, right of the WIC and left of the lounge; contains a bed and built-in cupboards.

•Passage

  • Floor Area: 6.205 m²
  • Description: central upper circulation, below the main bedroom and linking rooms to the lounge and bedroom; contains no fixtures shown.

•Lounge

  • Floor Area: 34.657 m²
  • Description: central upper room, right of the main bedroom and above the stair/void area; contains sofas, chairs and coffee table.

•Balcony

  • Floor Area: 40.311 m²
  • Description: at the back of the upper floor, above the lounge/main bedroom; contains no internal fixtures shown.

•Bathroom

  • Floor Area: 9.045 m²
  • Description: upper right, beside the lounge and stair area; contains bath, shower, toilet and basin.

•Bedroom

  • Floor Area: 19.446 m²
  • Description: lower middle-left of the upper floor, below the passage and left of the stair/void; contains a bed and built-in cupboards.

•Balcony

  • Floor Area: 11.359 m²
  • Description: at the front of the upper floor, below the bedroom; contains no internal fixtures shown.
6
Bedrooms
4
Bathrooms
2
Levels
488 m²
Floor Area
2
Garages
19.5 m
Length
33.2 m
Width
Price
R 6 434,01R 6 499,00Save 1%
PDF download

After secure payment, your full construction PDF is emailed to you and available to download immediately.
