4 BEDROOMS

4 BED

2 ENSUITE

KITCHEN

LOUNGE

DINING

GARAGE

STUDY

Design Description

GROUND FLOOR:

•Garage

  • Floor Area: 48.130 m²
  • Description: front left of the house, opening internally toward the central bedroom side; contains vehicle door opening.

•Patio

  • Floor Area: 14.223 m²
  • Description: at the back left, behind the main bedroom and en suite; contains no internal fixtures shown.

•En suit

  • Floor Area: 7.929 m²
  • Description: back left corner, opening off the main bedroom and next to the closet; contains bath, toilet, basin and shower.

•Closet

  • Floor Area: 9.234 m²
  • Description: between the en suit and main bedroom on the left side; contains no fitted fixtures shown.

•Main Bedroom

  • Floor Area: 25.584 m²
  • Description: upper left-central part of the house, right of the closet and below the rear patio; contains sliding door/window openings.

•Dining

  • Floor Area: 15.326 m²
  • Description: upper centre, between the main bedroom and kitchen and above the central passage; contains dining table and chairs.

•Kitchen

  • Floor Area: 19.081 m²
  • Description: upper right-centre, right of the dining and left of the bathroom passage; contains counters, sink, stove and central island.

•Bathroom

  • Floor Area: 8.615 m²
  • Description: upper right, off the passage between the kitchen and right bedroom; contains bath, toilet, basin and shower.

•En suite

  • Floor Area: 5.510 m²
  • Description: top right corner, opening off the upper right bedroom; contains bath, toilet, basin and shower.

•Bedroom

  • Floor Area: 16.213 m²
  • Description: upper far right, right of the bathroom and below its en suite; contains window openings.

•Passage

  • Floor Area: 14.289 m²
  • Description: central circulation space, connecting dining, main bedroom side, lower bedroom and living area; contains no fixtures shown.

•Bedroom

  • Floor Area: 17.091 m²
  • Description: left of centre below the main bedroom, opening off the central passage and next to the garage; contains window openings.

•Lounge

  • Floor Area: 30.085 m²
  • Description: lower centre, below the central passage and left of the study; contains sofas/chairs and sliding door openings.

•Study

  • Floor Area: 13.061 m²
  • Description: lower right-centre, right of the lounge and off the right-hand passage; contains no internal fixtures shown.

•Passage

  • Floor Area: 9.926 m²
  • Description: right of centre, linking the kitchen/bathroom area to the study and lower right bedroom; contains no fixtures shown.

•Bedroom

  • Floor Area: 15.515 m²
  • Description: lower right corner, below the upper right bedroom and right of the study; contains window openings.

•Patio

  • Floor Area: 9.890 m²
  • Description: front centre, below the lounge; contains no internal fixtures shown.

•Patio

  • Floor Area: 5.947 m²
  • Description: front right-centre, below the study; contains no internal fixtures shown.
4
Bedrooms
3
Bathrooms
1
Levels
335 m²
Floor Area
2
Garages
17.8 m
Length
25.6 m
Width
Price
R 4 209,00
PDF download

After secure payment, your full construction PDF is emailed to you and available to download immediately.
