4 BEDROOMS

4 BED

2 ENSUITE

KITCHEN

LOUNGE

DINING

GARAGE

STUDY

SCULLERY

BATH WITH SEPARATE TOILET

BRAAI AREA

Design Description

GROUND FLOOR:

•Scullery

  • Floor Area: 12.011 m²
  • Description: at the upper left, opening off the kitchen and beside the rear patio; contains counters/cabinets and a sink.

•Kitchen

  • Floor Area: 25.334 m²
  • Description: left side of the house, below the scullery and beside a patio, open to the central dining/living area; contains counters/cabinets, a sink, and a central island with stove/hob.

•Patio

  • Floor Area: 9.644 m²
  • Description: at the far left off the kitchen; contains no internal fixtures shown.

•En Suite

  • Floor Area: 4.718 m²
  • Description: left side between the main bedroom and dressing room; contains bath, shower, toilet and basin.

•Dressing Room

  • Floor Area: 8.671 m²
  • Description: between the en suite and the lounge/main circulation, next to the main bedroom; contains no fitted fixtures clearly shown.

•Main Bedroom

  • Floor Area: 21.558 m²
  • Description: lower left of the house, beside the dressing room and en suite, opening toward the lounge and left patio; contains no fixtures shown.

•Patio

  • Floor Area: 4.875 m²
  • Description: outside the main bedroom on the left side; contains no internal fixtures shown.

•Lounge

  • Floor Area: 40.331 m²
  • Description: central lower part of the house, between the main bedroom and study, below the dining; contains lounge furniture and doors/windows.

•Patio

  • Floor Area: 9.717 m²
  • Description: below the lounge at the front/bottom centre; contains no internal fixtures shown.

•Patio

  • Floor Area: 22.951 m²
  • Description: at the top centre, above the dining and beside the upper bedroom; contains table and chairs.

•Dining

  • Floor Area: 29.763 m²
  • Description: central upper part of the house, below the top patio, between kitchen/scullery and bedroom wing; contains dining table and chairs.

•Bedroom

  • Floor Area: 16.256 m²
  • Description: upper middle-right, off the dining area and left of the upper-right bedroom; contains no fixtures shown.

•Bedroom

  • Floor Area: 18.053 m²
  • Description: upper right, next to the bathroom and above the middle-right bedroom; contains built-in cupboard(s) marked SH/ST and a small WC/basin compartment adjacent.

•Bathroom

  • Floor Area: 12.225 m²
  • Description: right side, below the upper-right bedroom and above the small WC room; contains bath, shower, toilet and basin.

•Bedroom

  • Floor Area: 18.904 m²
  • Description: middle right, below the upper-right bedroom and right of the central circulation; contains no fixtures shown.

•WC

  • Floor Area: 4.685 m²
  • Description: lower right, between the bedroom wing and garage; contains toilet and basin.

•Study Room

  • Floor Area: 11.026 m²
  • Description: lower middle-right, between the lounge and garage, above the small front patio; contains no fixtures shown.

•Patio

  • Floor Area: 3.422 m²
  • Description: small patio at the front/bottom centre-right, between lounge/study and garage; contains no internal fixtures shown.

•Garage

  • Floor Area: 44.322 m²
  • Description: lower right/front of the house, beside the study and below the WC; contains garage parking space.
4
Bedrooms
3
Bathrooms
1
Levels
398 m²
Floor Area
1
Garages
20.5 m
Length
24 m
Width
Price
R 4 589,00
PDF download

After secure payment, your full construction PDF is emailed to you and available to download immediately.
