3 BEDROOMS

3 BED

1 ENSUITE

KITCHEN

LOUNGE

DINING

GARAGE

BATH

BRAAI

Design Description

GROUND FLOOR:

•Garage

  • Floor Area: 41.112 m²
  • Description: front left of the house, opening internally toward the central passage/study side; contains vehicle bay/door opening.

•Main Bedroom

  • Floor Area: 24.149 m²
  • Description: upper left, next to Bedroom and below Closet and En Suite, opening to the central passage; contains windows.

•Closet

  • Floor Area: 10.356 m²
  • Description: above the Main Bedroom at the top left, opening off the Main Bedroom side near the En Suite; contains no fitted items clearly shown.

•En Suite

  • Floor Area: 9.112 m²
  • Description: at the top centre-right of the Main Bedroom, between Closet and the top wall; contains bath, shower, two basins, toilet.

•Bedroom

  • Floor Area: 20.050 m²
  • Description: upper centre, to the right of Main Bedroom and left of Bathroom, opening to the central passage; contains windows.

•Bathroom

  • Floor Area: 7.113 m²
  • Description: centre-right, between the upper Bedroom and Dining/Lounge area; contains bath, shower, basin, toilet.

•Study

  • Floor Area: 8.912 m²
  • Description: lower centre-left, between Garage and lower Bedroom, opening off the central passage; contains window.

•Bedroom

  • Floor Area: 20.440 m²
  • Description: lower centre, to the right of Study and left of Lounge, opening off the central passage; contains windows.

•Lounge

  • Floor Area: 27.716 m²
  • Description: lower right, below Dining and left of the right-side Patio, opening to Dining and Patio; contains lounge seating and windows/sliding opening to Patio.

•Dining

  • Floor Area: 20.417 m²
  • Description: centre-right, between Kitchen above and Lounge below, left of the right-side Patio; contains dining table and chairs.

•Kitchen

  • Floor Area: 14.757 m²
  • Description: upper right, above Dining and beside the small left Patio; contains counters, sink, stove/hob, stair.

•Patio

  • Floor Area: 4.352 m²
  • Description: upper far right-left recess beside the Kitchen; contains no internal fixtures shown.

•Patio

  • Floor Area: 17.648 m²
  • Description: right side of the house, beside Dining/Lounge; contains outdoor table and chairs.

•Patio

  • Floor Area: 13.696 m²
  • Description: bottom right, below the Lounge; contains no internal fixtures shown.
3
Bedrooms
2
Bathrooms
1
Levels
292 m²
Floor Area
2
Garages
16.1 m
Length
23.5 m
Width
Price
R 3 590,00
PDF download

After secure payment, your full construction PDF is emailed to you and available to download immediately.
