2 BEDROOMS

2 BED

1 BATH

1 EN SUITE

KITCHEN

LOUNGE

Design Description

GROUND FLOOR:

•Garage

  • Floor Area: 51.691 m²
  • Description: at the left/front side of the house, opening to the lounge side; contains vehicle bay space and a garage door.

•Patio

  • Floor Area: 7.335 m²
  • Description: at the back of the house behind the kitchen; contains no internal fixtures shown.

•Kitchen

  • Floor Area: 14.856 m²
  • Description: at the back-left/centre, opening to the lounge and adjacent to the rear patio and bathroom side; contains counters, sink, stove/cooker and an island.

•Lounge

  • Floor Area: 27.785 m²
  • Description: central in the house, between the garage and passage, below the kitchen and above the front patio; contains fitted units/counters along two sides and sliding doors/windows.

•Bathroom

  • Floor Area: 9.923 m²
  • Description: at the back-right of the lounge, off the small hall near the kitchen and passage; contains bath, shower, toilet, basin and a store cupboard.

•Bedroom

  • Floor Area: 17.198 m²
  • Description: at the back-right corner, opening off the passage near the bathroom; contains a built-in cupboard/wardrobe and windows.

•Passage

  • Floor Area: 2.958 m²
  • Description: on the right side of the lounge, connecting the lounge to the bedrooms and bathrooms; contains door openings only.

•En Suite

  • Floor Area: 8.831 m²
  • Description: off the passage between the two right-side bedrooms; contains bath, shower, toilet, basin, linen/store cupboard and a WC/wardrobe area marked TRGR.

•Patio

  • Floor Area: 8.283 m²
  • Description: at the front centre below the lounge; contains no internal fixtures shown.

•Patio

  • Floor Area: 6.296 m²
  • Description: at the front-right outside the lower bedroom; contains steps.

•Bedroom

  • Floor Area: 27.930 m²
  • Description: at the front-right corner, opening off the passage; contains built-in cupboards/wardrobes and windows.
2
Bedrooms
1
Bathrooms
1
Levels
192 m²
Floor Area
2
Garages
15 m
Length
19.5 m
Width
Price
R 2 449,00
PDF download

After secure payment, your full construction PDF is emailed to you and available to download immediately.
